1.Automatic PLC control 2.Output:1920-10080pcs/h 3.Net weight:11.8t 4.Forming cycle:12-18s
Electric control system of Brick making machine
The electric control system consists of imported color touch screen and programmed PLC with data input and output device, including safety logical control and trouble shooting system.Vibration analyzing system:detecting the vibration frequency, vibration amplitude,vibration acceleration and noise of the whole machine,so as to adjust the vibration to optimum efficiency.
Mainframe of Brick making machine
The system consists of imported components and seals with high dynamic performance proportional valves. The action of key cylinders can be operated through the regulator of flow and pressure according to the working requirement.The main frame is wide for the convenience of mold filling, so more blocks can be made. In order to get even pressure, three oil reservoirs are used, which raise the pressure to as high as 100t. Moreover, the smallest reservoir in the middle increases the operating speed of the left and right ones respectively, thus improving the productivity.
Working principle of Brick making machine
Frequency conversion motor drive the vibrating case,easy to obtain ideal vibration force,vibration frequency and amplitude,can produce high quality block. Unique double-vibration box drives all in one vibration table to make the deviation of amplitude lower,more even so as to guarantee the consistency firm and durable.High thickness and rectangle steel frame, four guidance column, solidity structure and prolonged life.
