Large capacity charcoal and coal briquette machine

FOB Reference Price:Get Latest Price
US $5,000-50,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Briquette Machines
Condition:
New
Production Capacity:
1-30 T/h
Motor Type:
Stepper Motor
Power(W):
15kw
Place of Origin:
Henan, China (Mainland)
Brand Name:
JINGXIN
Dimension(L*W*H):
2200*1600*800MM
Certification:
ISO
Warranty:
one year
After-sales Service Provided:
Engineers available to service machinery overseas
type:
Large capacity charcoal and coal briquette machine
model:
JXMQ-5
Capacity (T/H):
5
Roller Diameter(mm):
522
Roller Width(mm):
212
Total pressure (tons):
14
Adjustable Line pressure (T/cm):
0.8
Roller speed(r/min):
17
Main power:
15
Reducer model:
ZQ500
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
charcoal and coal briquette machine packaged with wooden cases
Port
qingdao shanghai tianjin
Lead Time :
Shipped in 10 days after payment

Large capacity charcoal and coal briquette machine



Coal and charcoal b briquette machine describe:

The coal dust ball press is specially designed according to the characteristics of charcoal powder:

specially used for charcoal/coal powder industry, mainly used in producing kindle carbon and charcoal briquettes.

The final product that machine give is smokeless, non-toxic, non-toxic,no peculiar smell and environment protective,

applicable to the outdoor or indoor barbecue with ventilation, as the heat very large, production time is twice more

 than traditional.With advantages of high pressure, high molding rate, high output, easy operation, rare fly-ash, evenly distributed heat and stable quality.Ball press is widely used in metallurgy, mining,coal, refractory,abrasive,

 fertilizer, ceramics, etc.

 Charcoal ball machine feature:

1. High efficiency

2. Apply for many kinds of powder like charcoal, coal, mineral, metal.etc.

3. Make round type or pillow type or oblong type charcoal ball.

4. The products have high density, high strength, and high hardness



 Charcoal briquette machine model:

Model

JXMQ-5

JXMQ-10

JXMQ-15

JXMQ-20

JXMQ-30

JXMQ-35-40

Capacity

(T/H)

5

10

15

20

30

35-40

Roller Diameter(mm)

522

630

630

800

1000

1200

Roller Width(mm)

212

310

415

540

800

1000

Total pressure (tons)

14

30

60

130

200

270

Adjustable Line pressure (T/cm)

0.8

1.2

1.41

1.68

1.8

2.0



Roller speed(r/min)



17

17

17

16

16

16

Main power

15

30

37

55

75

110

Reducer model

ZQ500

ZQ650

ZQ850

ZQ1000

ZSY400

GDC1200

Hydraulic station model(Mpa)

DBD0.8

Rated pressure

Mpa8

Mpa10

Mpa12

Mpa14

Mpa16

Mpa20

Charcoal Briquette Machine2.jpgCharcoal Briquette Machine.jpg
