Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: JINGXIN
  • Model Number: JX
  • Voltage: 380V
  • Power(W): 18.5KW
  • Weight: 260KG
  • Dimension(L*W*H): 1200*1650*2100mm
  • Certification: ISO
  • Warranty: one year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • type: High efficiency durable coal and charcoal extruder machine
  • model: JXII-180
  • Capacityfor charcoal: 800-1200 kg/h
  • Capacity for coal: 2000-3000kg/h
  • Product specification: Diameter 20-60mm
  • Rotated speed: 39-60 r/min
  • Power: Y180Y180L-4 , 18.5kw
  • Reducer machine: ZQ400
  • delivery: wihthin 7 days
  • packing: wooden cases

Packaging & Delivery

Packaging Details High efficiency durable coal and charcoal extruder machine pachaged with wooden cases
Delivery Time Shipped in 10 days after payment

High efficiency durable  coal and charcoal extruder machine



1. Raw material: coal powder, charcoal powder, carbon powder, mineral powder, metal powder,coke powder,

 and other materials to make them folded. The powder size should be: 3mm-5mm



2. Working principle:

The motor transmits power to transmission through the belt. At the same time, the transmission output shaft transmits

power to propeller through the floating coupling, then the propeller shaft extrude the coal material by the molding die

to produce the ideal high-pressure coal-stick.



3. Characteristic :

1).  No binder or noxious chemical need to use.

2).  The humidity of the raw materials is controlled in 8-12%.

3).  Using the advanced Hot air drying system with the perfect performance.

4) After the processing of High temperature, purification, smoke removing, the carbonizing equipment transforms

 the semi-finished bio-fuel briquette into a smoke-free, tasteless, non-toxic cleaning carbon.



Coal and charcoal extruder machine parameter:

Model

JXII-140

JXII-180

JXII-220

Capacityfor charcoal

400-600 kg/h

800-1200 kg/h

1200-2000 kg/h

Capacity for coal

1000-2000 kg/h

2000-3000kg/h

4000-6000 kg/h

Product specification

Diameter 20-40mm

Diameter 20-60mm

Diameter 20-80mm

Rotated speed

46-60 r/minutes

39-60 r/min

46-75 r/min



Power

Y160L-4 , 11kw

Y180L-4 , 18.5kw

55 kw

Reducer machine

ZQ350

ZQ400

ZQ450

Dimension

1700*1200*600

2000*1400*700 mm

2300*1600*800
